Name: Intelligent Omni Directional Tunnel Lifting AGV Auto Guided Vehicle With Lithium Battery
Brand: CASUN
SKU: BFJ1500V2

Home Products Omni Directional Tunnel Lifting AGV

Intelligent Omni Directional Tunnel Lifting AGV Auto Guided Vehicle With Lithium Battery

Product Details:

Place of Origin:	China, Shenzhen
Brand Name:	CASUN
Certification:	CE
Model Number:	BFJ1500V2

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	USD
Packaging Details:	Wooden case
Delivery Time:	35 days
Supply Ability:	200 units / month

Contact Now

Detailed Product Description

Loading Capacity:	500-1500kg	Navigation:	Magnetic
Dimensions:	L1500W800H765(mm)	Battery:	Lithium
Direction:	Omni-Directional	Accuracy:	±10mm
High Light:	lift agv , autonomous guided vehicle

Omni-Directional Heavy Duty AGV Load 500-1500kg Lifting Plateform

1. Product Description:

Omni-directional lifting Platform AGV: The material can be lifted to the set height and transported to the support plate, and the space required for running is small. In a narrow space environment, the normal AGV can not complete the docking work, and its 360-degree rotation function can meet the requirements of setting different angles running on site, and effectively utilize the on-site space. Mainly suitable for environment with small space and heavy lifting required

2. Application:

This type of AGV is a customized model for one project of cold supply chain warehouse. It is designed special for food industry.

3. Specifications:

Product name	Omni Direction Tunnel Type with Lifting Platform AGV
Model	BFJ1500V2
Dimensions	L1500W800H765(mm)
Load capacity	1200kg
Minimum turning radius	0, Omni-directional driving
Guidance	Magnetic guidance
Travel Direction	360°Omni-directional driving
Travel speed	0-45m/min(Or customizing))
Guiding accuracy	±10mm
Stopping accurac	±10mm
Communication available	RF / Wifi
Driving mode	Differential driving
Power	DC24V
Workable	24 hours by optimizing automatic charging
Ramp	≤2°
Type	Lifting platform
Charging method	Manual charging / automatic charging
Battery	Lead acid battery / lithium battery
Life time	≥10 years
Alarm	Sound and visual
Safety features	Front obstacle sensor+mechanical bumper sensor
Safety induction range	Detecting range ≤3m, adjustable; Emergency braking distance: ＜20mm
