Unmanned Laser Guided Forklifts AGV 1 Ton Payload Precise Positioning

Unmanned Laser Guided Forklifts AGV 1 Ton Payload Precise Positioning

    • Unmanned Laser Guided Forklifts AGV 1 Ton Payload Precise Positioning
    • Unmanned Laser Guided Forklifts AGV 1 Ton Payload Precise Positioning
  • Unmanned Laser Guided Forklifts AGV 1 Ton Payload Precise Positioning

    Product Details:

    Place of Origin: China
    Brand Name: CASUN
    Certification: CE ISO9001
    Model Number: CJPSB15V1

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: USD
    Packaging Details: Wooden case
    Delivery Time: 35 working days
    Supply Ability: 200 units per month
    Contact Now
    Detailed Product Description
    Dimension: L1975*W796*H3943mm Speed: 45m/min
    Load Capacity: 1500kg Battery: Lithium Battery
    Alarm: Sound And Visual Type: Forklift
    High Light:

    agv forklift

    ,

    agv pallet truck

    Unmanned Laser Guided AGV Palletstacker 1 Ton Payload Mobile Robot





    1. Product Description:



    Product Description:Laser guiding forklift AGV (pallet stacker type) series products were developed according to the actual needs of different industries, mainly composed of AGV car body and lifting gear, etc. and are used for lifting & handling work with empty pallet , loading tray and paper rolls,etc.





    2. Application:



    Widely used for intralogistics solution for loading and uploading materials.





    3. Characteristic:



    1, Laser guidance, no need of magnetic tape and tap, easy to maintain.

    2, Could lift up to 2.9m or design based on customer’ requirement.

    3, Maximum capacity is 1.5T or design based on customer’ requirement.

    4, Be more flexible, and adaptable for different environments.

    5, Precise positioning, error value is in 10mm.





    4. Specifications:



    Product name Omni Direction Steering Wheel Tunnel Type with Roller Platform AGV
    Model BFQD1800V2
    Dimensions L1800*W680*H950mm or customizable
    Load capacity 200kg
    Minimum turning radius 0, Omni-directional driving
    Guidance Magnetic guidance
    Travel Direction 360°Omni-directional driving
    Travel speed 0-35m/min(Or customizing))
    Guiding accuracy ±10mm
    Stopping accurac ±10mm
    Communication available RF / Wifi
    Driving mode Differential driving
    Power DC24V
    Workable 24 hours by optimizing automatic charging
    Ramp ≤2°
    Type Platform type, omni-directional AGV
    Charging method Manual charging / automatic charging
    Battery Lead acid battery / lithium battery
    Life time ≥10 years
    Alarm Sound and visual
    Safety features Front obstacle sensor+mechanical bumper sensor
    Safety induction range Detecting range ≤3m, adjustable; Emergency braking distance: <20mm
