Name: Steering Drive Omni Directional Tunnel Lifting AGV Autonomous Guided Vehicle
Brand: CASUN
SKU: BFJ1500V2

Home Products Omni Directional Tunnel Lifting AGV

Steering Drive Omni Directional Tunnel Lifting AGV Autonomous Guided Vehicle

Product Details:

Place of Origin:	China, Shenzhen
Brand Name:	CASUN
Model Number:	BFJ1500V2

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	USD
Packaging Details:	Wooden case
Delivery Time:	35 days
Supply Ability:	200 units / month

Contact Now

Detailed Product Description

Model:	BFJ1500V2	Dimensions:	L1500W800H765(mm)
Load Capacity:	500-1200kg, Customizable	Travel Speed:	0-45m/min(Or Customizing))
Travel Direction:	360°Omni-directional Driving	Type:	Tunnel Lift
Drive:	Steering Drive	Coating:	White Or Custom
Industry:	Food Industry And Hospital
High Light:	lift agv , autonomous guided vehicle

Food Intralogistics Automated Guided Vehicle with Steering Drive Magnetic Tape Tunnel Lift Type

1. Product Description:

Omni-directional lifting Platform AGV: The material can be lifted to the set height and transported to the support plate with limited small space.

In a narrow space environment, the normal AGV can not complete the docking work, but its 360-degree rotation function can meet the requirements of setting different angles running on site, and effectively utilize the on-site space. Mainly suitable for environment with small space and heavy lifting required.

2. Application:

This type of AGV suits for food industry, especially for cold chain warehouse, and medical industry.

3. Specifications:

Product name	Food Intralogistics Automated Guided Vehicle with Steering Drive Magnetic Tape Tunnel Lift Type
Model	BFJ1500V2
Dimensions	L1500W800H765(mm)
Load capacity	500-1200kg or custom
Minimum turning radius	0, Omni-directional driving
Guidance	Magnetic guidance
Travel Direction	360°Omni-directional driving
Travel speed	0-45m/min(Or customizing))
Guiding accuracy	±10mm
Stopping accurac	±10mm
Communication available	RF / Wifi
Driving mode	Differential driving
Power	DC24V
Workable	24 hours by optimizing automatic charging
Ramp	≤2°
Type	Lifting platform
Charging method	Manual charging / automatic charging
Battery	Lead acid battery / lithium battery
Life time	≥10 years
Alarm	Sound and visual
Safety features	Front obstacle sensor+mechanical bumper sensor
Safety induction range	Detecting range ≤3m, adjustable; Emergency braking distance: ＜20mm
